Sunday, September 17, 2017

Camera Lenses

A Camera lens is a device that bends light, so that different light beams line up, preferably at the focal plane, which is where the film or sensor is located.  When this is true, it is said to be in focus, the earliest cameras had a single lens.  Since the film was so large in size, typically 4"x5", 5"x7", 8"x10", 11"x14" and 16"x20".  These numbers were not magical, they were simply standard window glass sizes, in the days of plate photography.  When sheet film came out, the same sizes were adopted.  However we are getting off track, if your negative is 8"x10" (20cm x 25cm) you can make things larger, by contact printing on 4x5" paper.

Eventually they developed  screw type lens mounts that allowed for changing lenses, and lenses of different sizes were developed.  It was quickly discovered that if you made the focal length shorter, the angle of view got wider, which meant more would fit in an image at a given distance from the camera, and depth of field increased.  News photographers would often use these benefits by fixing short lenses on their cameras.  Unfortunately there are also a disadvantage, straight lines would appear curved, and perspectives would change, an item that was close to the camera would appear much larger then normal, and an item further away would appear much smaller.  Photographers have used both of these traits to advantage.

By the same token longer lenses would have a narrower angle of view, less would fit in the image at the same distance,  straight lines would not be affected, but the perspective changes would be reversed, flattening the image.  Portrait photographers learned quickly that using a slightly longer than normal lens, was more flattering, with a 35mm camera 85mm - 100mm is about right.   In the 1960's they developed the bayonet mount, which made lenses easier and faster to change.  Unfortunately where with screw mount lenses nearly all camera's used the same 49mm mount, each bayonet could be a little different.  You could no longer use a lens made by one manufacturer, on another makes camera.  Although third party lens makers would quite often make lenses with different mounts on them, and one company Tamron made adaptall lenses which could be used with different makes of cameras, using different adapter rings.

A4601000
In the film days I used 4 lenses, a 28mm (wide, but not wide enough that the distortion wasn't livable), a 50mm, a 135mm and a 200mm, I have a 1.5x extender for that camera so it's really 28mm, 50mm, 100mm, 135mm, 200mm, 270mm and 400mm.  For digital, I have an 18-55 and a 70-300 which are a good combination, yes I realise that 56-69mm are not covered, but that isn't really an issue.   This camera uses a smaller sensor, giving a longer lens, for the Canon APS-C the 18mm is the same as a 29mm on the film camera, 55mm is the same as 88mm, the 70mm is the same as 112mm on a 35mm and 300 is more like 480mm on the 35mm.

This weeks image of a white lion was taken at African Lion Safari, last year, from a car with the windows closed, with the 70-300mm lens at 85mm on the Canon 300D.  It's a nice image, of a cat on the prowl, it's funny to see that a house cat uses similar methods when they are hunting.

I think that is all for now....

W.


Sunday, September 10, 2017

Analog versus Digital

This week we look at Analog versus digital imaging.  Each has advantages and disadvantages, but rather then simply list them, we should take a look at how they work in the real world.

Analog imaging is a chemical process, a silver salt, is a combination of silver and one of the halides, bromine, chlorine, iodine and fluorine.  Is exposed to light, producing a latent image, this is then amplified with another chemical to develop a visible image that is then processed with either sodium thiosulfate or ammonium thiosulfate which washes away the undeveloped salts.  This produces a negative, and by exposing this on another form of the same material, we can produce a positive.  If properly processed the images can be quite well preserved, for hundreds of years.  Although the chemicals have scary names, they really are not that dangerous, and some like the developer hydroquinone are used in medicine.  Interestingly enough, the most dangerous of the chemicals is actually silver, and modern labs will use recovery mechanisms to recover and recycle the leftover silver.  Yes the silver has value, but you need to process a lot of film, to get even a small amount.

One of the problems with the process, is that if you have a unrecoverable issue, such as an out of focus exposure, you can't erase it and do over, you need to use more film, and either throw it away, or leave it in the archive.  This has nothing on the printing process, where a good day in the darkroom, results in a few good prints, and a bin full of wet rejects.

Some of us, moved to a hybrid process, where you would shoot film, scan the film into a computer, and then do your editing on the computer, some even took and sent their printing to a wet lab. This can be difficult however, in that it can take a lot to get a good scan, and you can spend more time scanning then you do processing and printing in a darkroom.  This weeks image is such, taken in 2003 with a Konica FC-1 on Fujicolor ASA 400 film, it's a pretty good rendition of a wonderful image.   Some of us are now looking at using a digital camera to copy some of the older stuff, you need a macro lens though to get a 1:1 image, and that can be more tricky then anything else.  This is because I have  books of them, in my case going back 40 years, although much of the stuff from back then, I look at now, and think of it as crap.  Which is why as I mentioned a couple of weeks ago, I will probably never look at.

Then there is a fully digital process, digital cameras have pretty much eliminated all of the problems except one, there is no real way to archive images, the way the old B&W negatives could be put in a box and left for a century or more.  We will find that we need to copy images over to new media as old media types are replaced with new.  Just like 8" floppies were replaced with 5 1/4" which were replaced with 3.5", we will eventually see a day, where CD's and DVD's will disappear as usable medium, and billions of photographs will  disappear with them.  Digital formats will change over time, the JPEG files will be replaced with something else.  This becomes the question, if your great grandson finds a CD full of your Jpeg files, will he know how to retrieve them?

On that thought, enough for this week

W



Sunday, September 03, 2017

A walk in the woods

Occasionally here, I will do a story, and the story may come with several images, rather then just one image, sometimes it will be a photographic study, with a whole group of images.  Today we get such a narrative.   I know there will be more then one image, but as I write the text here, I don't know how many.

So last Sunday I said to my other half, that I would like to take a walk in the woods.  She said it sounded like a good idea, and looked at a few places, here in Southern Ontario, in Canada, there are 4 systems of parks, that you can choose from.  There are Federal Parks, there are Provincial Parks, City Parks and Conservation Areas.  She suggested Heart Lake Conservation Area. It's not that far from home, and while I get my walk in the woods, she and the kid, can do a shorter walk and then use the pool at the site.  I think they walked about 1 kilometre or so, I probably did closer to 10.

E4700418
A walk in the woods, is a great tool for destressing, it's not always quiet, in fact a forest by a lake can be quite noisy.  Birds, insects and frogs can be quite noisy, but somehow the sounds of nature  is less noisy than a street full of traffic.     The trail we took goes from the treetop zip line, to the border of someones private property, I didn't go quite that far.  We found some small frogs, I suspect these are Northern Leopard Frogs, as you can see from the surroundings they are quite small, they could be from this years crop.  Seeing animals like frogs in a murky lake, often means it is a healthy lake.  Lakes that are completely clear and devoid of fish and aquatic reptiles, often means that the lake is dead, from pollution.  Which is a sad thing to see,


E4700434
When one wants images of wild life, you really need to remember 2 things, you need a big lens, and to proceed as quietly as possible.  In this case the lens is a 70-300mm Zoom, it's a little soft all the way out, but that's partly because I didn't have the opportunity to set up a camera support.  I found this little guy just chilling on a log, and took a few images, before he noticed me, and took off.  I took about 100 images on the day, maybe 5 of this particular chipmunk, then picked the one I liked the best for the posting.  One of the others may find it's way into a later post.  I think if my wife and 5 year old had been around, I wouldn't have gotten any.   I need to teach the little one, that it's okay to not be speaking, and that we can sometimes see things that we would not otherwise see, when we make noise.
E4700478

E4700453
They were around, for the bumble bee though, and this was not taken with a long lens.  Sometimes Insects are tricky, especially ones that bite and sting, in that you don't want to scare them, if they feel threatened, they are more likely to sting or bite.  In this particular case though, I think this bee was too busy gathering nectar to take back to the hive.  Summer is winding down, and Bee hives need to prepare for winter.    Although honey bees and bumble bees can be very similar, bumbles appear scary hairy, and looking at this one it's most likely a bumble.  Interesting difference, with honey bees, a smaller portion of the colony winters over, with bumble bees only the queens hibernate.  Just in case you think all of the images I took, were of animal and insect life, there were some plant photos as well, like this last one.

Looks like these plants are pretty much done for this year.  The seed pods have already burst, and spread their seed for the winter.  What I try to keep out of photos, is the fact that many parks have a single problem.  That is people, many people are dirty, they leave garbage everywhere.  I am of the opinion that the only evidence you visited a natural place should be the photographs and images that you took.  If you create garbage in the woods, take it out with you, it's not hard, and it means that other folks can visit a nice clean place.

We are actually coming into one of the best times to walk in northern woods, Fall adds the wonder of colour as the world gets ready to shut down for winter.

Thanks, all for this week

W

Sunday, August 27, 2017

Exposure Part 2 - Making it work.

This week we look at more on making exposure work on a modern camera.  While early exposure based on the type of light worked, it wasn't really accurate enough, and the first light meters were the result.  At first the meter was a set of neutral density filters, and you would pick the proper filter, which gave your exposure.  This relied on the human eye, which is different person to person.  Then we saw the first electric meters, these were based on selenium, and operated as a type of photo-voltaic cell, it would when exposed to light produce a small voltage, the higher the voltage, the more light there was.  The result was a match-needle system, the voltage would be displayed and as you set the shutter speed or aperture, it moved another needle, when the two needles were matched, you had the correct exposure.   They were terrible in low light, and needed to be quite large, and ceased to be used in the 1960's when Cadmium Sulfide (CdS) based meters were developed.

These worked in a different way, by passing a voltage through the cell, as the light was higher or lower, the resistance was higher or lower.  These meters required a battery that would provide the same voltage from fresh until it suddenly dropped dead.  Mercury batteries had this characteristic and were cheap, until they were banned in the early 1990's.  Alkaline batteries which are cheaper and less toxic, tend to start at a higher voltage and gradually drop, requiring some form of voltage regulation circuit to provide a constant voltage to the cell.  Some meters still use CdS meters are still used, although other sensors are also used.  CdS cells could be quite small, and mounted inside the camera, giving a very good reflective light meter.

Manual mode, this one is for what you think the computer is likely to get fooled, for example when there is a lot of one tone, which isn't your primary subject, or your trying to do something creative.  A photographer by the name of Ansel Adams developed the zone system, for such circumstances.

Aperture Priority mode, when you want to control the aperture, and are not as concerned about the shutter speed.   For example your trying for a certain depth of field.

Shutter Priority mode, when you want to control the shutter speed, and are not as concerned about the aperture.  For example action shots.  Sometimes you will use it to freeze motion, and other times to emphasize it.  This can be very useful.

Program mode, your not really concerned about aperture or shutter speed, and just want an image.

Many modern DSLR Cameras also have "hint" modes, for example Sports or Portraits, these are similar to P mode, but will shift the values, based on the hint.  For example Sports mode, will attempt a high shutter speed to freeze action, Portraits mode will go for a higher aperture, to ensure a face is fully in focus.

B3400088
On my current regular camera, I use various modes, most commonly Av or Tv (shutter priority), there is the ability to shift the exposure by up to 3 stops,  so there is little need to use M mode anymore.  I also sometimes use the hint modes, I don't like P, but it is there....

This weeks image is from well back in the archive, it's a film image that was scanned, I don't remember from where, but I like the reflective nature of the image.  There are hundreds of these, that were scanned and never catalogued, and I am slowly getting them done. One thing I did do, was include some notes, in the exif data  and this one was originally shot on Agfa Vista 200 ASA Colour film, using the Konica FC-1 Camera.

I think that's about all there is for this week

W.

Sunday, August 20, 2017

Exposure Part 1

Early Cameras were totally manual in nature, you had two things to set, how fast the shutter would operate, and how much light enters the lens.  Even the latest high tech DSLR that has more computing power than an IBM/360, as the ability to make these two settings.  The majority of people don't really think about this, they let the computer to all the thinking, but that can result in a poor image.

Shutter speeds are counted in seconds, fast shutters can exceed 1/2000th of a second, and many can be held open for long periods of time.   The amount of light is expressed as a fraction of the focal length of a lens.  A lens that is 100 mm long, at f/4 will have an opening that is 25mm in size, these fractions are based on a series of numbers, where each number allows double or half the amount of light, the lower the number, the larger the amount of light, these numbers are logarithmic in nature.  The typical values are 1, 1.4, 2, 2.8, 4, 5.6, 8, 11, 16, 22, 32 although it's technically possible to go smaller then f/32 it would be quite rare, rare is another word for expensive.  In the 1970's and 1980's when 400 ISO (usually expressed as ASA in those days)  film was considered very fast, the standard lens was the 50mm, and most were between f/1.4 and f/2.  Current digital zooms, are quite a bit smaller, with f/4 to f/5.6 being common, then again with ISO values of 3200 and 6400 being common, this isn't a problem.

Early cameras were all manual, and you would use rules like Sunny 16, to determine exposure.  Then light meters came out, which would measure the light, and provide values to the photographer.  Now, fast shutter speeds can stop motion, such as in sports, the smaller the aperture, the greater the depth of field (range of distance of image that is in focus), the larger the number, the smaller the depth of field.  With the same lens, the shorter the lens, the greater the depth of field, and the longer the lens focal length, the shallower the depth-of-field.   A short lens with a small aperture can have a nearly endless depth of field.

A3700226
You can creatively make use of this.  The image below has the ice on the rock in the foreground and the much lake also in focus, it was taken on a bright winter day, with a small aperture.  in this case the exposure was f/11 with a 22mm lens and a shutter speed of 1/200, with an ISO of 100.  I know this, because the original image was taken with a digital camera, that records this.   So the rock that is only 2 metres away and the lake horizon 1km away, are both in focus.  With other items you can use a larger aperture and a longer focal length to throw a messy background out of focus.

Some photographers will intentionally use a slow shutter speed to emphasize movement, this can give a really nice effect to moving water, giving it a dreamy quality.

I try to keep these postings fairly short, as long postings can get dull and boring, More on this next week in Part 2on exposure, when I will go into the mechanics of making it work with the modern camera.

That's all for this week
W

Sunday, August 13, 2017

The editing process

So you go out shooting with your favourite camera, and come home with 500 images, now what? How do you decide what you will keep, and what will you throw away.

I almost never clear an image from the memory card, even if I know it's not going to be kept, for a couple of reasons,  when you started with 24 and 36 exposure film rolls, then 100 images "per roll" on a memory card is a lot.  After they are on the computer, I reformat the card.

The first edit I do, is a technical edit, if the image is poor, out of focus or wrong focus, the lighting or composition didn't work, then I toss the image.   I don't usually have time to play around with poor images, when I have dozens or hundreds of images to deal with.  The remainder get catalogued, and honestly, may of them will never see the light of day.   Others can sit in the archive for years, and then get pulled out for processing.   Then of course, we all have our favourites, this is one of mine.  I think before I stopped the blog before, I had this one posted.

A3600019
This weeks image is actually an old favourite of mine, it was taken on the first shoot with the Canon 300D (Digital Rebel) a camera that is now heading into semi-retirement.  My brother-in-law and I, were out driving around, and we saw this place, no signs for no-trespassing were about, and we took a few shots.  It is interesting how, a building sometimes will start to come apart.  This actually was a common design in the late 1800's.  It's called a storey and a half, a later modification was the storey and three-quarters where the side walls would be extended up further to give more head height.

As with most images, this was shot in colour, then processed to black and white through my normal mechanism.

I'll admit that this week is a little short, but I ended up writing this on Saturday afternoon, with a sore back that seems ready to give out.  I'll try for something more interesting next week

W

Sunday, August 06, 2017

My workflow for digital images.

I shoot everything in RAW mode, this is because JPEG, the normal output for most digital cameras, is a lossy format, it loses some of the image data that the algorithm, deems unimportant. If you normally, simply take your memory card to Walmart, and feed it into their machine for a bunch of prints, or your post everything on Facebook or Instagram, this is fine. If you like to do post processing of your images, then it’s not fine.  The reason for this is that it throws away a little more of the image each time, so after a few edits there is nothing really left.  Back in the days when disk space cost $1/MB and a 56K modem was considered blindingly fast; the need for high compression was worth the cost of lower quality.  Today when $100 buys a 2TB drive, and 10Mbit/second is considered slow, we don't need as high compression.
I consider the RAW file, as the undeveloped film, I use RAW conversion software (UFRAW), as a standard developer which leaves me with a PNG file; essentially a transparency or slide, rather than a negative. I go through, and any that are obviously unable to be salvaged, get sent to the trash folder. Some that are iffy, I will go back to the original RAW file, and load it into the conversion software, and play with it, to see if I can get a better result. If the result is not usable, then it also gets moved to trash.

The rest are fed through a custom program that issues them catalogue numbers, and moves them to the archive. It’s still a work in progress and will eventually get rewritten to become more efficient and to work better, but currently it works well enough.  I want to eventually get it to do the raw conversion, as one thread then show the image in a second thread, so I can either accept or reject it, and then catalogue it, again in a third thread.

When I am considering images for use, I go back through the archive and see if I can find what I want, these are then fed through another bit of custom software, that does a bunch of things, like re-sizing, conversion to black and white, toning, adding the copyright notice, etc. If something doesn’t work, I fix it, will it ever be ready for public consumption, probably not. The end of the process is a Jpeg file, either suitable for printing or for posting.
E4700329


If you think you need a fancy new Mac for this, you don’t, I use a 10 year old PC that runs Fedora Linux on it, I can load images into Gimp which will allow intermediate processing, but often use my own software so that I can get the same result each time.

This weeks image, Catalog Number E4700329, I like the angle on this one, it's unusual and the petals have a translucent effect on the front, because the sun was above and slightly to the right of the flower.  The background is actually leaves that are dark green, they turn black when converted to black and white.

I think that is all for this week, see you next.

W
